Author Topic: EEVblog #1104 - Omicron Labs Bode 100 Teardown  (Read 5892 times)

sorin and 3 Guests are viewing this topic.

Offline precaud

  • Frequent Contributor
  • **
  • Posts: 370
  • Country: us
    • LinearZ
Re: EEVblog #1104 - Omicron Labs Bode 100 Teardown
« Reply #125 on: August 09, 2018, 10:55:43 am »
That's was mistake in my conceptual thinking, whatever. I assumed, measuring the signal output at one side of the power divider would compensate for the total loading effect on the source. But it doesn't, it attenuates the loading effect to a lower impedance seen by the VNA - assuming using a resistive power divider. Anyway, measuring both the transformer input and output with high impedance R and A, then calculating A/R removes the loading effect of the transformer from the result. That's nearer to a virtual zero source impedance than the power divider method.

Well there can be good reasons for looking at it either way. I'm just concerned that future readers of this thread will look at all the measurements as if they're the same, when they're not.

Quote
rx8pilot:
You'd normalize the  "FRA" setup by setting the VNA to sweep A/R phase and amplitude, the replace the transformer by a "through" and normalize. The 3577A then normalizes these traces (resulting in "A/R/D1" / "A/R/D2" as traces). This is at least how I'd normalize this setup. precaud pls confirm.

Yes, and make sure whatever you'll be loading the xfmr with is in place for the sweep you use for normalizing.

Quote
precaud:
At above some 10MHz the high impedance input mode of the 3577A doesn't work too well anymore, because of the 50 Ohm impedance of the internal and external cables involved. For lower frequencies, high Z should work fine and wouldn't require normalization anyway.

Yes, for true high-Z measurements that wold be true. But not so much for a device with a 50 to 75 Ohm term. You can use normalize to test the impedance sensitivity of the measurement setup. Ex: normalize a "thru" sweep with 50 Ohm term, then change to a 75 Ohm term and it will plot the deviation. Anything that is not a flat line is a problem... phase deviation would be the most sensitive.

That's phenomenal bandwidth you're getting through that xfmr! What is it rated for?



Offline rx8pilot

  • Super Contributor
  • ***
  • Posts: 3199
  • Country: us
  • If you want more money, be more valuable.
Re: EEVblog #1104 - Omicron Labs Bode 100 Teardown
« Reply #126 on: August 09, 2018, 11:10:49 am »
This thread has thrown me down a rabbit hole of thoughts, self-education, and experiments. Only learning more about magnetics and properly measuring them with a 25-year-old VNA can get me out of the hole.

Factory400 - the worlds smallest factory. http://www.youtube.com/c/Factory400


Offline T3sl4co1l

  • Super Contributor
  • ***
  • Posts: 10988
  • Country: us
  • Expert, Analog Electronics, PCB Layout, EMC
    • Seven Transistor Labs
Re: EEVblog #1104 - Omicron Labs Bode 100 Teardown
« Reply #127 on: August 09, 2018, 01:05:12 pm »
This thread has thrown me down a rabbit hole of thoughts, self-education, and experiments. Only learning more about magnetics and properly measuring them with a 25-year-old VNA can get me out of the hole.

If it gets more people measuring, it can't be a bad thing. :)

Tim
Seven Transistor Labs, LLC
Electronic Design, from Concept to Layout.
Need engineering assistance? Drop me a message!

The following users thanked this post: precaud

Offline capt bullshot

  • Super Contributor
  • ***
  • Posts: 1007
  • Country: de
    • Mostly useless stuff, but nice to have: wunderkis.de
Re: EEVblog #1104 - Omicron Labs Bode 100 Teardown
« Reply #128 on: August 09, 2018, 03:16:32 pm »

That's phenomenal bandwidth you're getting through that xfmr! What is it rated for?

Don't know. Found it by chance on the evilbay (looking for North Hills after someone mentioned their transformers here), and decided to give it a try. No datasheet, no information, no similar part number found on the North Hills website. BTW, they've got some app notes about transformers and other interesting stuff.
So I just could guess: It's a RGB + sync video transformer, so I expected it to have wide BW to be useful, or it would be a common mode choke (North Hills calls them "Humbucker"). Former analog monitors having BNC RGB inputs achieved video bandwiths in excess of 100MHz.

http://www.nhsignal.com/products-wideband-video-isolation.html
Safety devices hinder evolution


Offline ehughes

  • Frequent Contributor
  • **
  • Posts: 302
  • Country: us
Re: EEVblog #1104 - Omicron Labs Bode 100 Teardown
« Reply #129 on: August 10, 2018, 07:01:11 am »
For what its worth,    Omicron got at least 1 sale as a result of the tear down.    I just ordered one for QA checking out transducers.     Once it is up an running, I'll post some measurement results.

The following users thanked this post: rx8pilot, 2N3055

Offline precaud

  • Frequent Contributor
  • **
  • Posts: 370
  • Country: us
    • LinearZ
Re: EEVblog #1104 - Omicron Labs Bode 100 Teardown
« Reply #130 on: August 12, 2018, 04:01:04 am »
I see now where the 10 Ohms term comes from. Omicron uses is as the reference R for their low-Z measurements using the transformer:

https://www.omicron-lab.com/applications/detail/news/low-value-impedance-measurements/

I'm surprised they're not getting a higher useful bandwidth using the 10 Ohm reference (which also determines the minimum load on the transformer). I get 100kHz using similar topologies using a 1 Ohm reference.


Offline T3sl4co1l

  • Super Contributor
  • ***
  • Posts: 10988
  • Country: us
  • Expert, Analog Electronics, PCB Layout, EMC
    • Seven Transistor Labs
Re: EEVblog #1104 - Omicron Labs Bode 100 Teardown
« Reply #131 on: August 12, 2018, 04:12:29 am »
Bandwidth is maximum at Zo, and drops off slowly for Z <> Zo.  The first-order approximation is thus: if LL and Lp are constant, then the LF cutoff is Z / (2*pi*Lp) and the HF cutoff is Z / (2*pi*LL).

For the frequencies and materials we're talking about here, this should be pretty close.  Note that the HF cutoff is actually a transmission line effect, not a dominant pole, so it will have slightly different response into other resistances (I forget if this is better or worse for BW).  For worse quality materials (like laminated iron), the permeability dependence on signal level and frequency is probably an important factor.

Tim
Seven Transistor Labs, LLC
Electronic Design, from Concept to Layout.
Need engineering assistance? Drop me a message!


Offline precaud

  • Frequent Contributor
  • **
  • Posts: 370
  • Country: us
    • LinearZ
Re: EEVblog #1104 - Omicron Labs Bode 100 Teardown
« Reply #132 on: August 13, 2018, 01:25:57 am »
This is a pretty interesting video, Ray Ridley comparing the three commercially-available isolation xfmrs at low frequencies.



Unit "P" is clearly the Picotest.
Unit "O" is the Omicron.
I do wish he had also plotted transmission curves vs freq over the whole range of the transformers, measured into the same load R.
I had the Ridley 15MHz unit and it had a 10dB dip starting at around 10kHz, regardless of load.


Offline chris_leyson

  • Frequent Contributor
  • **
  • Posts: 922
  • Country: wales
Re: EEVblog #1104 - Omicron Labs Bode 100 Teardown
« Reply #133 on: August 13, 2018, 02:16:17 am »
The Omicron Labs B-WIT 100 is only supposed to be driven at 0dBm not 13dBm. Interesting video from Omicron Labs where product "R" gets tested.



Offline precaud

  • Frequent Contributor
  • **
  • Posts: 370
  • Country: us
    • LinearZ
Re: EEVblog #1104 - Omicron Labs Bode 100 Teardown
« Reply #134 on: August 13, 2018, 02:38:24 am »
Yeah, the 15MHz Ridley unit I had looked similar in terms of flatness, though smoother at the high end than that one. The freq resp dip bugged me and so I sold it (perhaps hastily).
However, one could argue that, as long as the response does not change with level or load, and the variations are not extreme, for most FRA work, ultimate flatness is not critical...
« Last Edit: August 13, 2018, 02:57:07 am by precaud »


Online Wolfgang

  • Regular Contributor
  • *
  • Posts: 239
  • Country: de
  • Its great if it finally works !
    • Electronic Projects for Fun
Re: EEVblog #1104 - Omicron Labs Bode 100 Teardown
« Reply #135 on: August 13, 2018, 03:29:48 am »
Unfortunately, neither Ridley nor Omicron tried to be especially objective with their presentations.

What would have been helpful are S21 curves that go over the whole frequency range, at given load impedances (e.g. 1/5/10/20/50 Ohms),
plus a curve for the allowable signal level for, say, 1% distortion over frequency, also for different load impedances. Also phase response is important
to know about.

It is very clear than one single device hardly fits all needs (High bandwidth, tolerant to strong signals with no distortion, low capacitances, not bulky ...)

There will versions with a deep low frequency limit - they are heavy and bulky, have a high coupling capacitance
There are smaller ones, which are small signal only, have medium frequency ranges, but lower capacitances, ...
...and the HF ones with very high bandwidth, very small signal tolerance, and small capacitance.

All marketing claims made in this industry has to be taken with a huge ROCK of salt. So have these videos.





Offline Kleinstein

  • Super Contributor
  • ***
  • Posts: 4332
  • Country: de
Re: EEVblog #1104 - Omicron Labs Bode 100 Teardown
« Reply #136 on: August 13, 2018, 05:36:16 am »
If a really good injection transformer is that difficult, I would consider thinking about an active solution, with optical isolation, thus a kind of analog opto-coupler. In a simple form something like 2 photo-diodes in parallel to a load resistor. Without amplification it would be likely limited to low power (e.g. a few 10 mV) - but chances are it could work from DC to  beyond 10 MHz with low coupling capacitance.  If it needs an amplifier for the output this could be battery powered for good isolation.


Online Wolfgang

  • Regular Contributor
  • *
  • Posts: 239
  • Country: de
  • Its great if it finally works !
    • Electronic Projects for Fun
Re: EEVblog #1104 - Omicron Labs Bode 100 Teardown
« Reply #137 on: August 13, 2018, 05:44:54 am »
Yes, this is a valid approach. If it is battery-powered and has a very fast (also low noise) optical isolator it competes very well with transformer solutions, especially at the low frequency range.


Offline ehughes

  • Frequent Contributor
  • **
  • Posts: 302
  • Country: us
Re: EEVblog #1104 - Omicron Labs Bode 100 Teardown
« Reply #138 on: August 17, 2018, 04:12:08 am »
We just got our Bode100.   It is a very nice piece of equipment and the software that come along is useful.    We are doing some analysis of a 1.8MHz piezo ring.  Specifically,  we are able to evaluate the epoxy in a transducer assembly.

Yet nice piece of equipment and easily worth the money for our QA setup.

The following users thanked this post: rx8pilot

Offline voltsandjolts

  • Supporter
  • ****
  • Posts: 542
  • Country: gb
Re: EEVblog #1104 - Omicron Labs Bode 100 Teardown
« Reply #139 on: August 19, 2018, 06:11:55 am »
I was browsing the Picoscope site (I'm interested in their flexres 16bit/8bit scopes with arb gen that can do FRA) and found quite a nice video link about measuring loop gain with a DIY signal injection transformer. Looks like a nanocrystaline core from a common mode choke with about 7 metres of TP each for primary/sec - its at 9:00 minutes in, but the whole video is quite well done. Didn't achieve the bandwidth that others have here tho >:D

« Last Edit: August 19, 2018, 06:26:28 am by voltsandjolts »


Offline precaud

  • Frequent Contributor
  • **
  • Posts: 370
  • Country: us
    • LinearZ
Re: EEVblog #1104 - Omicron Labs Bode 100 Teardown
« Reply #140 on: Yesterday at 02:32:32 pm »
Here's a good reason NOT to use the Jensen IsoMax transformer for gain- and phase- margin measurements above 20kHz - above which the phase response changes with impedance... caused by the bandwidth increasing with increasing load R. The North Hills units are all better in this range.


Offline DualTriode

  • Contributor
  • Posts: 8
  • Country: us
Re: EEVblog #1104 - Omicron Labs Bode 100 Teardown
« Reply #141 on: Today at 07:34:55 am »
Hello,

What you have shown is that the leakage inductance and load resistance form a low pass filter.

What you have not shown is that accuracy of the VNA Bode Plot is diminished.

The Bode Plot Phase Margin is independent of the transformer phase.(within limits) The VNA software has provisions to compensate for the attenuated transformer HF gain. (within limits)

DT



Offline precaud

  • Frequent Contributor
  • **
  • Posts: 370
  • Country: us
    • LinearZ
Re: EEVblog #1104 - Omicron Labs Bode 100 Teardown
« Reply #142 on: Today at 09:01:26 am »
What you have not shown is that accuracy of the VNA Bode Plot is diminished.

I haven't "shown" it, but I guarantee you it definitely is diminished, unless some post-processing is used to correct for it (Open/Short/Load). But even then, if the change is not fairly linear over the entire measurement range, the compensation math won't b able to correct for it accurately.

Quote
The Bode Plot Phase Margin is independent of the transformer phase.(within limits).

Not in my experience.

Quote
The VNA software has provisions to compensate for the attenuated transformer HF gain. (within limits)

Yes, some VNAs have "provisions" for it, but I have never seen any example of someone "normalizing" their VNA with the transformer in place prior to making a control loop measurement.


Offline rx8pilot

  • Super Contributor
  • ***
  • Posts: 3199
  • Country: us
  • If you want more money, be more valuable.
Re: EEVblog #1104 - Omicron Labs Bode 100 Teardown
« Reply #143 on: Today at 09:12:06 am »
Curious why you started at 4R7.

What are you using to test it? How did you calibrate? I may do the same test to see if the results are similar (although I may use higher value loads) - but would want to match what you did.
Factory400 - the worlds smallest factory. http://www.youtube.com/c/Factory400


Offline precaud

  • Frequent Contributor
  • **
  • Posts: 370
  • Country: us
    • LinearZ
Re: EEVblog #1104 - Omicron Labs Bode 100 Teardown
« Reply #144 on: Today at 09:36:54 am »
Curious why you started at 4R7.

I didn't;  I started at 1R0, and ended at 4R7    :-DD

Most of what I use these for (output impedance measurements) loads the transformer between 1R0 and 5R0 on the high end. See the setup in this post:
http://www.eevblog.com/forum/blog/eevblog-1104-omicron-labs-bode-100-teardown/msg1720265/#msg1720265

For the measurement I posted, the setup is the same xfer function setup as others I've posted; both inputs at 1M, R measures xfmr input, T measures the output.

Quote
What are you using to test it?

AP Instruments 102B

Quote
How did you calibrate?

Huh? You want me to explain the 102B's cal procedure?

Quote
I may do the same test to see if the results are similar (although I may use higher value loads) - but would want to match what you did.

Please do. I get the same results regardless of the analyzer used.
« Last Edit: Today at 09:46:27 am by precaud »


Offline chris_leyson

  • Frequent Contributor
  • **
  • Posts: 922
  • Country: wales
Re: EEVblog #1104 - Omicron Labs Bode 100 Teardown
« Reply #145 on: Today at 09:50:00 am »
@voltsandjolts Nice video from Picoscope, thanks. Something has been bugging me about using 1:1 transformers and them terminating the secondary with 5 or 10 ohms. I would have gone for 2:1 or most probably 3:1 for a 5 ohm load. If I get time this week I will have a stab at a 3:1 transformer and see how it goes.


Offline DualTriode

  • Contributor
  • Posts: 8
  • Country: us
Re: EEVblog #1104 - Omicron Labs Bode 100 Teardown
« Reply #146 on: Today at 03:21:29 pm »
Hello,

Open/Short/Load calibration is used for the impedance accessory test fixture and is not part of the VNA frequency gain / phase plot.

If you look in the Keysight E5061B User’s Manual you will the Open/Short/Load calibration procedure for Impedance Analysis option and optional impedance test fixture(s).

The available adjustment for the Frequency Gain / Phase Margin test is signal level. There is no adjustment needed for transformer phase.

The available test signal adjustment is for amplitude. The generator output level is adjusted to be within the small signal range of the DUT error amplifier. Over the LF range the signal level may need to be trimmed to reduce noise. Over other frequency bands the signal may need other tweaking. This tweaking is a iterate process looking for the cleanest Bode plot. This tweaking is more about the DUT than the injection transformer. (within limits)

DT


Online Wolfgang

  • Regular Contributor
  • *
  • Posts: 239
  • Country: de
  • Its great if it finally works !
    • Electronic Projects for Fun
Re: EEVblog #1104 - Omicron Labs Bode 100 Teardown
« Reply #147 on: Today at 09:05:31 pm »
I agree completely.

The properties of your isolation transformers determine your dynamic range, even if the phase and amplitude response can be calibrated out by a good VNA.

What I do not understand in a lot of cases why manufacturers insist so much on a 1:1 ratio. I do not know a lot of examples except PFC where high signal injection amplitudes at low frequencies are really needed; In the absolute majority of cases you need rather small amplitudes in the millivolts range in order not to drive the DUT out of its linear range.

I did it with COTS ISDN transformers and a matching network., and it worked fine.
