Ohm's Law (just a funny pic)
« on: April 03, 2013, 05:36:50 am »
Is this an oldie or a good one ?

Logged


Offline Ed.Kloonk

  • Super Contributor
  • ***
  • Posts: 4000
  • Country: au
  • Cat video aficionado
Re: Ohm's Law (just a funny pic)
« Reply #1 on: April 03, 2013, 06:01:21 am »
I haven't seen it before and I think its a very good way to explain what I've tried in the past to explain, and explain, explain.   >:(

They say a pic tells a thousand words. And I'm going to steal and use it. Sorry.

Logged
iratus parum formica


Offline staxquad

  • Frequent Contributor
  • **
  • Posts: 417
  • Country: ca
  • Eye Candy
Re: Ohm's Law (just a funny pic)
« Reply #2 on: April 03, 2013, 06:31:16 am »
Quote from: opablo on April 03, 2013, 05:36:50 am
Is this an oldie or a good one ?

easy to understand ohms law depiction




Logged
"TEPCO Fukushima you long time"
You say Vegemite, I say Yosemite. (Ve-gem-mit-tee, Yo-zey-might)
"For starters : you're Canadian...."


Offline gnif

  • Administrator
  • *****
  • Posts: 1714
  • Country: au
  • Views and opinions are my own
    • AMD
Re: Ohm's Law (just a funny pic)
« Reply #3 on: April 03, 2013, 07:41:31 am »
Quote from: staxquad on April 03, 2013, 06:31:16 am
Quote from: opablo on April 03, 2013, 05:36:50 am
Is this an oldie or a good one ?

easy to understand ohms law depiction



I get the voltage is the pressure on the bottle, the resistance is the nozzle, and the current is the flow of sauce... but where does the kid and the chips come into it? :P
Logged


Offline staxquad

  • Frequent Contributor
  • **
  • Posts: 417
  • Country: ca
  • Eye Candy
Re: Ohm's Law (just a funny pic)
« Reply #4 on: April 03, 2013, 09:00:35 am »
Quote from: gnif on April 03, 2013, 07:41:31 am


I get the voltage is the pressure on the bottle, the resistance is the nozzle, and the current is the flow of sauce... but where does the kid and the chips come into it? :P

the kid generates the pressure (electromechanical generator)

the chips are the reason the kid's switch was turned on
Logged
"TEPCO Fukushima you long time"
You say Vegemite, I say Yosemite. (Ve-gem-mit-tee, Yo-zey-might)
"For starters : you're Canadian...."


Offline tom66

  • Super Contributor
  • ***
  • Posts: 7218
  • Country: gb
  • Electronics Hobbyist & FPGA/Embedded Systems EE
Re: Ohm's Law (just a funny pic)
« Reply #5 on: April 03, 2013, 09:11:34 am »
Perhaps would need some indication of the voltage drop across the resistor, for example, a smaller volt character at the other end?
